Model: ES- XL-KSSD-2LR-T6

Name: Tactical strobe red laser sight and strobe 500 lumens led light combo, the led light with strobe function and the red laser is a quick start constant or strobe red laser.

Product Origin: China

Supply Ability: 1000 pcs/month

Minimum Order: 100 pcs

Delivery Lead Time for MOQ: 20 days

TECHNICAL DESCRIPTION

Wavelength: 635nm

Power Output: 3 W

Laser Type (mw): 5

Battery:  18650 rechargeable 2200mAh battery  3.7V 1pc

Continuous Runtime:  2.5 hours )both green laser with led light working on), 57 hours (only laser), 2.5 hours (only led light)

LED detailed information

LED model: CREE T6 LED

Power: 3W

Diameter: Ø 8 mm

Length: 202 mm

LED brightness: Up to 500 lumens blinding beam, Bright sidelight

LED radiation angel: 240 degree

Light color: Cold white

Working Temperature:-40 ~ +55

Light attenuation: Less than 3% after 10k hours

Life time: ≤ 50000 hours

Laser detailed information

Diameter: Ø 5.6 mm

Length: 5 mm

Wavelength: 532 nm

Working Temperature: -20 ~ +50 (-4°F~122°F)

Laser Spot Diameter:  30-40mm @ 30m

Life time: ≤ 5000 hours

Working volt: 3.7V

Weight with Battery: 305.60g

Warranty: Extended Warranty of 1 year

Construction: Aluminium alloy 6061-T6 with black anodized finish

Finish: Anodic oxidation/ V' r3 black

Operation: Ambidextrous Momentary/Steady on-off Switch

Rail type: MIL-STD-1913 Picatinny Rail

KIT INCLUDES

Laser sight and LED Flashlight integrated group

Calibration tools

1PC 18650 rechargeable 2200mAh battery  3.7V

User manual

PACKING

Unit Weight: 2.3 kgs
G. W: 28.5 kgs
N. W: 26.2 kgs
CTN: 8 PCS
Carton Size: 62cmX52cmX28cm

Individual packge: The aluminium case with the outer color box

Warranty: 1 Year Limited warranty.

FEATURES

Quick target acquisition

Lightweight

Compact

Safe and adjustable

Dust and Shockproof

Ambidextrous Momentary/Steady on-off Switch

Machined anodized aluminum housing

Fits existing light bearing holsters

Adjustable mount flexibility that can accommodate the Glock or Picatinny (1913) accessory rails.

LASER SIGHT and LED LIGHT ZEROING

For a laser mounted below or to the side of the bore, there is only one distance where the bullet path will coincide with the laser sight line, this point is the zero range.

Laser adjustment and the muzzle velocity of the bullet determine where this point occurs. The user must decide how high above or below the sight line the bullet can be allowed to strike and adjust the sight accordingly. At distances less than the zero range the bullet will be above the sight line. Beyond the zero range the bullet will be the sight line.

If mounted to the side, the bullet will also deviate to the side of the laser line, as well as up and down. In practice, a KSSD with laser combo on a machine gun can be adjusted to keep the bullet strike within about 2 high and 2 low out to about 100 feet.

The LED also can adjust the windage and elevation with the intalled windage and elevation adjustable mount.

....
